| Specification | Details |
|---|---|
| Model | D-80A |
| Power Output | 2400 W × 4 @ 8 Ω |
| Output Circuitry | Class H |
| Frequency Response | 5 Hz – 50 kHz (+0.5 dB) |
| Input Sensitivity | 0.775 V / 1 V / 2 V |
| Input Impedance | 20 kΩ (Balanced) / 10 kΩ (Unbalanced) |
| Damping Coefficient | > 600 |
| Signal-to-Noise Ratio | > 102 dB |
| THD + N | < 0.05% @ 8 Ω, 1 kHz |
| Cooling System | 4 temperature-controlled large fans |
| Chassis Size | 3U Rack-Mount |
| Protections | Thermal, Overload, Short-Circuit |
